Equipment List
| No | Equipment | Company | Q'ty | Detail | |
|---|---|---|---|---|---|
| 1 | OTA Chamber | 2G/3G + LTE + GPS + WIFI + BT | KTM | 3 | Passive & Active |
| 2 | LTE | MT8820C / CMW500 | Anritsu / R&S | 3 | LTE, LTE-A,(FDD & TDD) |
| 3 | WIFI | MT8860C | Anritsu | 2 | 802.11b/g/a/n |
| 4 | NB-IoT | MT8821C | Anritsu | 1 | NB-IoT, LTE-cat-M1 |
| 5 | S-Parameter N/A | E5071C | Agilent | 3 | 30kHz ~ 8.5GHz |
| 6 | S-Parameter N/A | 8753ES | Agilent | 2 | 30kHz ~ 6GHz |
| 7 | CDMA / WCDMA / GSM | E5515C | Agilent | 3 | 2G/3G Test Set |
| 8 | GPS S/G | GSS 4100 | Sprinet | 1 | - |
| 9 | Bluetooth | Iqcell / TC-3000 | Litepoint / Tescom | 1 | ZigBee/wifi가능 |
| 10 | Spectrum Analyzer | E4440 | Agilent | 1 | Vector S/A |
| 11 | Signal Generator | E4438C | Agilent | 1 | Multi-tone, modulation |
| 12 | Noise Figure Analyzer | N8973 | Agilent | 1 | - |
OTA Chamber - 2G/3G + LTE + GPS + WIFI + BT
LTE - MT8820C / CMW500
WIFI - MT8860C
NB-IoT - MT8821C
S-Parameter N/A - E5071C
S-Parameter N/A - 8753ES
CDMA / WCDMA / GSM - E5515C
GPS S/G - GSS 4100
Bluetooth - Iqcell / TC-3000
Spectrum Analyzer - E4440
Signal Generator - E4438C
Noise Figure Analyzer - N8973
Chamber #1
Chamber #2
Chamber #3
Measurement environment
